VERTICAL LAMINAR AIR FLOW S.S.

Made of S.S. 304 complete with HEPA Filter and Pre Filter, motor blowers, static manometer, cock for gas and air or vacuum line. Front doors are made of plexiglass transparent thick sheet framed with Stainless Steel sheet built in U.V. tube. Work table is illuminated by florescent light. Whole LAF cabinet is fitted on
detachable table of S.S. Front door can be slide full open/half open, fully close as desired. But Laminar flows down vertically from top towards the work table. Supplied complete with hairline finished stainless steel table top. Transparent front door made of plexi glass. The equipment is fitted with safety attachments of international standards.

FEATURES OF CONTROLLER :

Password (Programmable) for Authorized Operation.
Real Time Clock.
UV Timer.
Initial Self Cleaning Cycle.
Total UV used Time.
Total HEPA Filter run time.
HEPA Filter Alarm after programmed hours with ON/OFF
Audio Visual Door unsafe alarm, if door is at incorrect operating height.
Display in down flow velocity (Sensor Model-Duo).
Door safe position alarm sounds if door is raised above correct operating height (Sensor Model).
Cabinet temperature display (Sensor Model -Uni and Duo).
UV light in work chamber inter locked with door & fluorescent lights i.e. it switches ON only when door is closed and automatically switches OFF fluorescent lights 30
minutes Auto off timer.

KLI/721

SKU: KLI/721 Category: Laboratory Instruments

Additional information

Additional information

Description	working Chamber, Size of HEPA Filter, No. of HEPA Filter, No. of Pre Filter, Illumination, U.V. Germicidal Light
A	2’ x 2’ x 2’, 2’ x 2’ x 6”, 1, 1 x 20W, 1 x 1 ft
B	3’ x 2’ x 2’, 3’ x 2’ x 6”, 1, 1 x 20W, 1 x 1 ft
C	4’ x 2’ x 2’, 4’ x 2’ x 6”, 1, 1 x 20W, 1 x 3 ft
D	6’ x 2’ x 2’, 3’ x 2’ x 6”, 2, 1, 2 x 20W, 1 x 3 ft

Available Options

SKU	Description	A	B	C	D
KLI/721/01	working Chamber	2’ x 2’ x 2’	3’ x 2’ x 2’	4’ x 2’ x 2’	6’ x 2’ x 2’
KLI/721/02	Size of HEPA Filter	2’ x 2’ x 6”	3’ x 2’ x 6”	4’ x 2’ x 6”	3’ x 2’ x 6”
KLI/721/03	No. of HEPA Filter	1	1	1	2
KLI/721/04	No. of Pre Filter	1 x 20W	1	1	1
KLI/721/05	Illumination		1 x 20W	1 x 20W	2 x 20W
KLI/721/06	U.V. Germicidal Light	1 x 1 ft	1 x 1 ft	1 x 3 ft	1 x 3 ft
